New Holland Electronic Service Tools(CNH EST 9.4 9.2 8.6 engineering Level ) CNH DPA5 kit diagnostic tool Plus lenovo X230 laptop
The software is 9.4 9.2 engineering level,CNH EST8.6 software is dealer
level.engineering level has more functions than dealer level and CNH 9.4
9.2 is with diagnostic procedure.
1.If you choose CNH EST 8.6 Dealer Level Software, we will provide you
with a registration machine, and you can activate the software yourself
2.If you choose CNH EST 9.4 9.2 Dealer Level Software for 1 PC
activation (we will remote help you installation by teamviewer) Full
: English, Italian, Russian, Polish, Spanish, French, Portuguese, German, Dutch, Danish.
The brand new version of New Holland CNH EST works with OS Windows 8 64
bit / 8.1 64 bit / 10 64 bit, except Home editions). If you have
windows 7, we can offer you a previous version of CNH EST, as the 9.4
versions no longer support Windows 7 and in some cases won't even
New minimum PC specifications
All computers must use a 64-bit version of their operating system. The
older 32bit options are limited to 4 gigabytes of RAM, and cannot
provide enough performance to run these programs.
Processor: Intel Core i5 Processor or higher;
RAM Memory: 8 GB or greater;
Operating System: Windows OS: 64-bit (Mandatory)
Windows 10 (Recommended)
Hard Drive: 250 GB or greater;
Ports: One 9 pin Serial port (preferred) OR USB to RS-232
Converter - FTDI Chipset)
Two USB ports
WiFi 802.11b / g
Mobile Wireless (recommended)
The following brands of the CNH group are covered:
New Holland (Agriculture and Construction)
New Holland FK (Fiat-Kobelco)
New Holland O&K (Orenstein & Koppel)
CASE (Agriculture and Construction)
Iveco (Astra) (articulated dump trucks only)
New Holland Electronic Service Tool allows you to:
• Check the status of parameters;
• Retrieve faults;
• Run diagnostic tests;
• Make ECU and parameter programming;
• Monitor active and logged diagnostics;
• View and change ECU configuration;
• View diagnostic procedures and schematics.
• Troubleshoot problems;
• Run scope diagnostics;
E.A.S.y - additional engine diagnostic and download tool for connection
directly to ECU to perform diagnostic, programming and ECU reload by
CNH Engine Download Tool operates from within the EST program to perform the following engine download operations:
• Provide Engine Control Unit (ECU) programing update capability;
• Provide blank ECU initialization and programming capability;
• Provide ECU programming reassignment for blank and other ECUs;
• Provide ECU download crash recovery.
This DPA5 can perform diagnostic, programming and ECU reload by K-Line protocol with E.A.S.y software for Iveco engines.
CNH DPA5 Interfaces OEM 380002884. This interface is Working 2 CAN and
K line ( for diagnostic CASE and New Holland with IVECO Engine with
EASY under EST
Second Hand Laptop Lenovo X230 Laptop Specification ：
Screen Size: 12.0
Processor Type: Intel (R) Core(TM) I5-3320M CPU
Processor Speed: 2.80 GHz
Processor Configuration: Dual Core
Compared with other laptop, this one is better quality and run faster.
1.Second Hand Laptop Lenovo X230 Laptop （All software activated. All system ready to use）
2.Dearborn Protocol Adapter 5 (DAP5 white interface) full New interface for New holland and Case
4.New 9-pin Deutsch CNH cable
One Year Warranty
